Customizing Labels
Setting the Label Length
You can set the length of label or block.
MEMO
• This cannot be set for a die-cut label.
• When creating a special label, you can set the length again.
Setting items for the special label is displayed after pressing .
1. Press .
2. Select the setting method of the length with
/ and press .
Auto: Automatically adjusts the label length
depending on the length of text.
Set: Sets the label length.
Setting range: 1.00 to 99.99 cm
3. Select the alignment for the text with
/ and
press
.
Left, Center, Justify, Right
Setting the Margins
Sets the left and right margins.
MEMO
You may not be able to set the margins depending on the label
type you create.
1. Press .
2. Select the type of margins with / and press
.
Tape width /3:
Sets margins that are 1/3 of the tape width.
Tape width:
Sets margins that are equal to the tape width.
Changing the Text Orientation +
Changes the text orientation to vertical or horizontal.
MEMO
You may not be able to change the text orientation depending on the
label type you create.
1. Press + .
Each time you press
+ , the setting switches
between " Horizontal" and "Vertical".
Horizontal
Vertical
MEMO
The items that can be set vary depending on the label type you create.

Panduit MP300 Specifications

General

Print technology	-
Maximum resolution	360 x 360 DPI
Maximum printing width	- mm
Display	LCD
Product color	Black, Grey
USB port	Yes
Certification	RoHS
Cables included	USB

Weight and Dimensions

Width	295 mm
Height	97 mm
