Changing the Printer Settings
Auto cut
Auto cut:
Sets whether or not to cut automatically.
Half cut:
When "Auto cut" is set to "On", the "Half cut" function is
available. "Half cut" will cut through just the label material,
but not the liner material, to make the label easy to remove.
Print density
Sets the print density.
Print density can be adjusted to improve print quality, if
needed.
Drop stop
This function will hold printed labels in place until they are
removed. After being removed, the next label will begin
printing automatically. This pause function stops the printed
labels from dropping out of the printer and holds them for
easy removal.
When printing multiple copies, printing of the second or
later labels starts each time you remove a printed label.
This function is only available when the label length is 1.1
inches (28 mm) or more, "Auto cut" is set to "On", and "Half
cut" is set to "O".
MEMO
If you perform continuous printing with the Drop stop function
enabled, printing may not be automatically resumed after you
take out the printed tape. In such a case, open and close the top
cover and choose "Print restart".
Die-Cut pos
Adjusts the text position on a die-cut label.
Width pos: Adjusts the vertical positioning of text.
Length pos: Adjusts the horizontal positioning of text.
Backlight
Sets the display backlight to On or O.
Language
You can select the language shown on the display from the
following:
Dansk, Deutsch, English, Español, Français, Italiano, Nederlands,
Norsk, Português-Br, Português-EU, Suomi, Svenska, Türkçe
inch/cm
The unit of length used to indicate the label size can be
switched between inch and cm.
MEMO
Version: The printer rmware version number.
Procedure for setting
1. Press .
2. Select the desired function with
/ and
press
.
3. Select the desired item with
/ and press .

Panduit MP300 Specifications

General

Print technology	-
Maximum resolution	360 x 360 DPI
Maximum printing width	- mm
Display	LCD
Product color	Black, Grey
USB port	Yes
Certification	RoHS
Cables included	USB

Weight and Dimensions

Width	295 mm
Height	97 mm
