Paradox Digiplex DGP2-640 User Manual

640 Icon LCD Keypad 33n
Figure 2: Delayed Fire Zone
Delayed Fire Zone
triggered
Bell/siren activated. Transmission of the report
delayed for 30 seconds. The fire alarm icon
will appear on the LCD screen.
Has the problem been
corrected within the 30 second
delay?
Yes
No
Has a second Delayed Fire
Zone triggered within the 30
second delay?
Bell/siren
continues and Fire
Alert report sent to
the monitoring
station.
Has any key been pressed
within the 30 second delay?
Bell/siren silenced. Transmission of the Fire Alert
report delayed an additional 90 seconds. The fire
alarm icon will flash on the LCD screen.
Problem corrected within the
90 second delay?
END
Alarm disabled
Yes
Yes
Yes
No
No
No
DGP2640_EU00.fm Page 33 Friday, April 8, 2005 11:28 AM
