KEYSWITCH PROGRAMMING
The Digiplex Control Panel can support up to 8 keyswitch zones in addition to 48 standard zones. A keyswitch
allows a user to arm or disarm a system by pressing a button or by toggling a keyswitch. The keyswitches are
connected to the hardwired-input terminals of either the Digiplex Control Panel, Zone Expander Modules or the
Keypad. For more information on the installation of keyswitches, please refer to in section 2.14. Keyswitches must
be assigned to a keyswitch zone and that zone must be defined as described in this section:
• Serial # of the Module
• Input # of the Module
• Keyswitch Definitions
• Keyswitch Partition Assignment
• Keyswitch Options
The Keyswitch Numbering feature enables you to individually assign each input to any keyswitch zone in the Digiplex
system. Please refer to section 6.1 of this manual for details. The Keyswitch Parameters define the keyswitch’s partition
assignment and its arming method (see sections 6.2 to 6.4).
Press & hold the
[0] key
Keyswitch Definition
First Digit
Keyswitch Partition
Assignment
Second Digit
Keyswitch Options
Feature Select
Enter 8-digit
[SERIAL NUMBER ] of module to
which keyswitch is connected
Enter 3-digit [INPUT NUMBER ]
of module to which
keyswitch is connected
Key-in
[INSTALLER CODE]
Press [ENTER ]
Figure 6.1 - Keyswitch Programming
Key in 3-digit
[SECTION ]
Select one only
Keyswitch Parameters
Sections [149] to [156] represent
keyswitches 1 to 8 respectively
Select
only one
Keyswitch Numbering
Sections [049] to [056] represent
keyswitches 1 to 8 respectively
Set the [5] key
on/off and select
one arming option
Keyswitch Definitions
1- Momentary Keyswitch
2- Maintained Keyswitch
Keyswitch Partition
Assignment
1- Keyswitch Assigned to Partition 1
2- Keyswitch Assigned to Partition 2
3- Keyswitch Assigned to Partition 3
4- Keyswitch Assigned to Partition 4
Keyswitch Options
[1] to [4] Future Use
[5] On = Arm Only Off = Arm/Disarm
[6] * Stay Arming
[7] * Away Arming
[8] * Instant Arming
*Select one only; if all are off, defaults
to regular arming.
}
Keyswitch
Parameters
[149] to [156]
}
Keyswitch
Numbering
[049] to [056]
