- 32 -
Account Codes for partitions 1 through 4. Partition
account numbers can be any hexa-digit from 0 to F.
Example:
If a zone generates an alarm in Partition 1, the
control panel will send Partition Account Number 1
followed by the appropriate report code.
9.5 REPORTING FORMATS
Section [550]
The Digiplex Control Panel can use a number of
different reporting formats and each of the four
Central Station Phone #’s (see section 9.3) can be
programmed with a different reporting format. The
first digit entered into section [550] represents the
reporting format (see table 9.2) used to communicate
with central station telephone number 1, the second
digit represents telephone number 2 and so forth.
9.5.1 Standard Pulse Formats
The Digiplex Control Panel can use the Ademco,
Silent Knight and Sescoa standard pulse reporting
formats (see table 9.2).
9.5.2 Ademco Express
The Ademco Express is a high-speed reporting
format, which communicates 2-digit (00-FF) report
codes programmed into sections [600] to [702], at a
speed of 2 seconds per report code. Unlike other
Ademco formats, the Ademco Express does not use
the Contact ID Report Codes.
9.5.3 Ademco Contact ID
Ademco Contact ID is a fast communicator format
that uses tone reporting instead of pulse reporting.
This communicator format also uses a pre-defined
list of industry standard messages and report codes
that will suit most of your basic installation needs. To
manually program the report codes, key in the 2-digit
hexadecimal values from the “Contact ID Report
Codes List” in the Programming Guide into the
desired report codes in sections [600] to [702] (see
section 9.2 of this manual). You can also enter 00
to disable reporting or FF to use the default report
code from the “Automatic Report Code List” in the
Programming Guide. To automatically program a
set of default contact ID codes, refer to section 9.13
of this manual.
9.5.4 SIA FSK
SIA FSK is a fast communicator format that uses
tone reporting instead of pulse reporting. This
communicator format uses a pre-defined list of
industry standard messages and report codes that
will suit most of your basic installation needs. To
manually program the report codes, enter 00 to
disable reporting or FF to use the default report
code from the “Automatic Report Code List” in the
Programming Guide. To automatically program a
set of default SIA FSK codes, refer to section 9.13
of this manual.
9.5.5 Pager Reporting Format
Using this format allows the control panel to
transmit report codes to a pager. A pound “#” is
automatically generated. Please refer to Pager
Delay in section 9.12.
9.6 EVENT CALL DIRECTION
Sections [522] to [535]
As shown in figure 9.1, the Control Panel events are
divided into three event groups for each partition and
two global event groups. Each event group can be
programmed to dial up to four central station
telephone numbers and one of four back-up
telephone numbers for each partition. The numbers
are dialed sequentially starting from 1, skipping any
disabled numbers and stopping once all selected
telephone numbers have been reached. If the
control panel fails to report to one central station
telephone number. After the Maximum Dialing
Attempts (see section 9.6.1), the control panel will
dial the selected back-up telephone number, unless
the Alternate Backup Option is enabled (see section
9.6.3). In which case it will dial the backup number
after every failed attempt.
Table 9.2 - Reporting Formats
0 = Ademco slow (1400Hz, 1900Hz, 10BPS)
1 = Silent Knight fast (1400Hz, 1900Hz, 20BPS)
2 = Secscoa (2300Hz, 1800Hz, 20BPS)
3 = Ademco Express (DTMF 4+2)
4 = Reserved for Future Use
5 = Ademco Contact ID
6 = SIA FSK
7 = Pager
