ZONE PROGRAMMING
All detection devices, whether connected to the control panel, keypads or zone expander modules must be
assigned to a zone and that zone must be defined as described in this section:
• Serial # of the Device/Module
• Input # of the Device/Module
• Zone Definition
• Zone Partition Assignment
• Zone Options
The Zone Numbering feature enables you to individually assign each detection device to any desired zone in the
Digiplex system. Please refer to section 5.1 of this manual for details. The Zone Parameters define the type of zone, the
zone’s partition assignment and how the control panel will react when an alarm condition occurs on that zone (see
sections 5.2 to 5.4). For more information on the installation of devices and modules, please refer to section 2 of this
manual.
Press & hold the
[0] key
Zone Definition
First Digit
Zone Partition
Assignment
Second Digit
Zone Options
Feature Select
Enter 8-digit
[SERIAL NUMBER] of the bus
detection device or of the
module to which a hardwire
device is connected
Enter 3-digit [INPUT NUMBER ] of
module to which device is
connected
NOTE: For motion detectors and
keypads no input # is required
Key-in
[INSTALLER CODE]
Zone Definitions
0- Disabled 6- Instant
1- Entry Delay 1 7- 24Hr Buzzer
2- Entry Delay 2 8- 24Hr Burglary
3- Entry Delay 3 9- Delayed 24Hr Fire
4- Entry Delay 4 A- Stand. 24Hr Fire
5- Follow
Zone Partition Assignment
1- Zone Assigned to Partition 1
2- Zone Assigned to Partition 2
3- Zone Assigned to Partition 3
4- Zone Assigned to Partition 4
Zone Options
[1] Auto Zone Shutdown
[2] Bypass Zone
[3] Stay Zone
[4] Force Zone
[5] [6] Zone Alarm Type
off off Audible Alarm (steady)
off on Audible Alarm (pulsed)
on off Silent Alarm
on on Generates only a report
[7] Intellizone
[8] Delay before transmission
Press [ENTER ]
Figure 5.1 - Zone Programming
Key in 3-digit
[SECTION ]
Select one only
Zone Parameters
Sections [101] to [148] represent
zones 1 to 48 respectively
Select
only one
Zone Numbering
Sections [001] to [048] represent
zones 1 to 48 respectively
Select one
or more
}
Zone Parameters
[101] to [148]
}
Zone Numbering
[001] to [048]
