INTRODUCTION
Paradox Security Systems has once-again redefined
the boundaries of the security industry and is proud
to introduce the Digiplex Control Panel. A new
generation in control panel technology, the Digiplex
Control Panel uses a quad-wire communication bus
(DIGI-BUS) which provides power and two-way
communication with up to 95 modules (keypads,
motion detectors, expander modules, etc.). This
combined with 4 true partitions, event call direction
and the zone numbering feature, simplifies the task
of installing or making changes to your security
system. The innovative new programming method
makes programming the control panel logical and
much simpler to execute. This new generation of
control panels offers increased capabilities with
countless new features without compromising its
user-friendliness. If anything, these new control
panels are easier to use and easier to install,
making the Digiplex Control Panel the ultimate in
reliable security protection.
1.1 FEATURES
• DIGI-BUS (4-WIRE COMMUNICATION BUS):
Ø Provides power and two-way communication
to all modules connected to the DIGI-BUS.
Ø 95 module support
Ø All bus modules have “Plug & Play”
capability
Ø Connect modules up to 3000ft (914m) from
the control panel.
Ø Full System Supervision.
• 48 fully programmable zones
• 8 independent keyswitch zones (does not use
any of the 48 zones)
• 4 on-board hardwired input terminals for use with
non-bus detection devices (expandable to 48).
• 4 True Partitions:
Most features and options in the Digiplex
System can be independently set for each
partition such as event reporting, entry/exit
delay, bell squawk, quick arming, panics and
many more. All zones, keyswitches, user codes
and keypads are assigned to specific partitions,
making this a true partitioned system.
• 63 User Codes, 1 Installer, 1 Master
• 4 fully programmable outputs (PGMs). PGM1
can be set as a 2-wire smoke detector input.
Optional 5A relay also available.
• Simple, direct and logical programming
• Event Call Direction:
The Digiplex Control Panel events are divided
into three event groups for each partition and
two system event groups. Each event group can
be programmed with a separate dialing
sequence for each partition.
• 4 Central Station Telephone Numbers
• SIA, Contact ID, Pager Format and many more
Communicator Formats
• Upload/download capability using new Paradox
upload/download Software for Windows.
• And much, much, more…
1.2 SPECIFICATIONS
• AC Power: 16VAC, 20/40VA, 50-60Hz
• Battery: 12VDC, 7Ah minimum
• Aux. Power:
2 outputs, each @ 12VDC 1.1A max.
• Bell Output: 1A, fuseless shutdown @ 3A
• PGM Output: PGM1 (100mA), PGM2 – PGM4
(30mA) and PGM5 (5A optional relay)
• Event Buffer: 736 events
1.3 ACCESSORIES
LCD Keypad (DGP-641)
48-zone, 32-character programmable LCD keypad
that connects to the DIGI-BUS. Most messages in the
LCD keypad are programmable. View zone, event
and trouble status for one or more partitions, display
entry/exit delay, adjust contrast, backlight, and many
other features. On-board PGM output and hardwired
zone input.
LED Keypads (DGP-610 & DGP-620)
The cost-effective 10-zone and 20-zone LED
keypads connect to the DIGI-BUS and provide a user-
friendly display of the system’s status. Includes on-
board PGM output and hardwired zone input.
ZX4 Zone Expander Module (DGP-ZX4)
Connected to the control panel’s EXPANSION input,
this module will add 4 hardwired-input terminals to
the Digiplex System (8 zones with ATZ enabled).
