7 Programming Guide
Codes and Panel Reset
IMPORTANT: When using an SP Series panel, all wireless sections and options do not apply unless an RTX3 is used in
conjunction with the panel.
IMPORTANT: When using an SP6000 panel in conjunction with an RTX3, all K32 and K10V/H keypads must be versions
2.0 or higher.
IMPORTANT: The K32I Fixed LCD keypad module is only compatible with MG/SP panel version 2.30 and higher.
System Overview
Viewing Version Numbers
Installer Code (Default: 0000 / 000000)
The Installer code is used to enter programming mode, which allows you to program everything
except
user codes. To change the default code, go to section [397] on page 8 and refer to sec-
tion [701] option [1] on page 23.
Maintenance Code (No Default)
The Maintenance code is used to enter programming mode, which allows you to
program everything except
for user codes and communication settings (sections [395], [397],
[398], [815], [816], [817], [910], [911], [970], and [975]). To set the default code, go to section
[398] on page 8 and refer to section [701] option [1] on page 23.
System Master Code (Default: 1234 / 123456)
The System Master code can use any arming method and can program user codes. To change
the default code, go to section [399] on page 8 and refer to section [701] option [1] on page 23.
Panel Reset
Press and hold the RESET switch for five seconds. When the STATUS LED flashes, press the
RESET switch within 2 seconds. However, this will not clear a bus module trouble (see section
[955]). To reset the panel to default using section programming (see section [950]).
Module Description
Maximum num-
ber per system
Current
Consumption
K32RF, K32IRF 32-Zone Wireless Keypad Modules 8 total Wireless
K10V/H, K32,
K32LCD,
K32I,
K636
10 and 32-Zone Hardwired Keypad Module
15 total including
ZX8
and RTX3
K10V/H: Min. = 44mA / Max. = 72mA
K32: Min. = 49mA / Max. = 148mA
K32LCD: Min. = 43mA / Max. = 86mA
K32I: Min. = 30mA / Max. = 70mA
K636: Min. = 28mA / Max. = 33mA
ZX8
ZX8SP
8-Zone Expansion Module 3 Min. = 29mA / Max. = 31mA
RPT1 Magellan Wireless Repeater Module 2 Average = 57mA
VDMP3 Plug-In Voice Dialer 1 Min. = 28mA / Max. = 28mA
IP100 Internet Module 1 Min. = 90mA / Max. = 120mA
RTX3 Wireless Expansion Module (Spectra SP only) 1 Min. = 61mA / Max. = 143mA
PCS100 GSM Communicator Module 1 Min. = 400mA / Max. = 1A
Example:
Version 01.42.
Digits 1-4
Step Action Details When Viewing Keypad Version
1 Enter Viewing Mode:
-For panel version, Enter section [980].
-For keypad version, Enter Installer Programming,
then press and hold [
ARM].
The first digit is displayed
(usually “0”)
Digit 1 D [
ARM] is illuminated
2 Press [
ENTER] The second digit is displayed. Digit 2 D [SLEEP] is illuminated
3 Press [
ENTER] The third digit is displayed. Digit 3 D [STAY] is illuminated
4 Press [
ENTER] The fourth digit is displayed. Digit 4 D [OFF] is illuminated
NOTE: K10V/H / K636 keypad version numbers cannot be viewed.
