Paradox Magellan MG5050 User Manual

19 Programming Guide
Zone Definitions
If a zone is already programmed and you assign a device to the same zone, a wireless zone will overwrite a keypad/hardwire
zone, and a keypad zone will overwrite a hardwire zone.
To program zone definitions, zone partitions and assign options:
Table 1: Zone Definitions
For more zone options, see sections [705] and [706] on page 24.
Step Action Details
1 [
ENTER] + [INSTALLER CODE]
(default: 0000 / 000000)
[ARM] + [STAY] = flash. [MAINTENANCE CODE] may also be used.
2 Enter 3-digit zone you wish to program
[001] to [032]
[
ARM] + [STAY] = on (see page 20)
3 Enter a 2-digit zone definition 2 digits: 01 to 32 (see Table 1 below)
4 Assign Partition
[1], [2] or [3]
By default, all zones are assigned to partition 1. (see Table 2)
5 Select or deselect zone options using
buttons [1] to [8]
For zone options, see Table 3. For keyswitch options, see Table 4.
6 To save and proceed to the next zone,
press [
ENTER]
Zone Definitions Stay Arm Sleep Arm Fully Arm Zone Definitions
00 = Zone Disabled (default) - - -
11 = Instant Fire†
01 = Entry Delay 1 Entry Delay 1 Entry Delay 1 Entry Delay 1 12 = Delayed Fire†
02 = Entry Delay 2 Entry Delay 2 Entry Delay 2 Entry Delay 2 13 = Instant Fire Silent†
03 = Entry Delay 1 (Full Arm)
Not Armed Not Armed Entry Delay 1 14 = Delayed Fire Silent†
04 = Entry Delay2 (Full Arm) Not Armed Not Armed Entry Delay 2 15 = 24Hr. Buzzer
05 = Follow Follow* Follow* Follow* 16 = 24Hr. Burglary
06 = Follow (Sleep/Full Arm)
Not Armed Follow* Follow 17 = 24Hr. Hold-up
07 = Follow (Full Arm) Not Armed Not Armed Follow 18 = 24Hr. Gas
08 = Instant Instant* Instant* Instant* 19 = 24Hr. Heat
09 = Instant (Sleep/Full Arm)
Not Armed Instant* Instant 20 = 24Hr. Water
10 = Instant (Full Arm) Not Armed Not Armed Instant 21 = 24Hr. Freeze
* Flex-Instant = Zone will follow the delay at section [720], (default is 15 seconds / 0 = instant zone) 22 = 24hr. Panic††
** On-board hardwire control panel zones and ZX8 expansion zones only 23 = Follow No Pre-Alarm
† APR-ZX8 inputs do not support fire zones.
For 2-wire smoke installations (not supported by SP5500), these definitions apply to Zone 1 Input
only. Section [706], option [3] must be enabled.
For 4-wire smoke installations, use any panel on-board zone input.
†† This alarm will follow the Panic 1 option (section [702], option [1])
24 = Instant No Pre-Alarm
25 = Keyswitch Maintain**
26 = Keyswitch Momentary**
[1]- N/A
[2]- N/A
[3]- N/A
[4] OFF = Disarm
ON = Disarm only if Stay/Sleep
armed
[5] = Arm only
[6] = Stay arming‡
[7] = Sleep arming‡
[8] = N/A
‡ Select only one. If all are off, key-
switch will regular arm.
[1] = Auto-zone Shutdown
[2] = Bypassable Zone
[3] =
RF Zone Supervision
[4] [5]
OFF OFF Audible Alarm
OFF ON Pulsed Alarm
ON OFF Silent Alarm
ON ON Report Only
[6] = Intellizone
[7] = Delay alarm transmission
[8] = Force Zone
[1]- Partition 1†
[2]- Partition 2†
[3]- Both partitions†
†
When using a K636 keypad, only
partition 1 is available.
Table 2: Partition Assignment Table 3: Zone Options Table 4: Keyswitch Options

Paradox Magellan MG5050 Specifications

General

Partitions	2
User Codes	32
Event Buffer	256
Built-in Transceiver	Yes
Remote Control	Yes
Wireless Keypads	Yes
StayD Mode	Yes
Remotes	Up to 32
Power Supply	16.5 VAC
Zones	32
Battery Backup	7Ah
