Zone Programming
For keypad zone programming, see page 31.
Zone Recognition (MG Series)
When expanding zones via ZX8, up to 3 ZX8 modules can be added to the system and are identified by the ZX8 3-position jumpers +1,
+9 and +17.
If a zone is already programmed and you assign a device to the same zone, a wireless zone will overwrite a keypad/hardwire
zone, and a keypad zone will overwrite a hardwire zone.
Zone Recognition (SP Series)
When expanding zones via ZX8, up to 3 ZX8 modules can be added to the system and are identified by the ZX8 3-position jumpers +1,
+9 and +17.
MG5000 No ATZ MG5000 ATZ MG5050 No ATZ MG5050 ATZ
Panel Zone 1: Panel Input 1 Zone 1: Panel Input 1A Zone 1: Panel Input 1 Zone 1: Panel Input 1A
Zone 2: Panel Input 2 Panel Zone 2: Panel Input 2A Zone 2: Panel Input 2 Zone 2: Panel Input 2A
Zone 3: Input 1 Zone 3: Panel Input 1B Panel Zone 3: Panel Input 3 Zone 3: Panel Input 3A
Zone 4: Input 2 Zone 4: Panel Input 2B Zone 4: Panel Input 4 Zone 4: Panel Input 4A
ZX8 Zone 5: Input 3 Zone 5: Input 1 Zone 5: Panel Input 5 Panel Zone 5: Panel Input 5A
Jumper Zone 6: Input 4 Zone 6: Input 2 Zone 6: Input 1 Zone 6: Panel Input 1B
Panel + 1 Zone 7: Input 5 ZX8 Zone 7: Input 3 Zone 7: Input 2 Zone 7: Panel Input 2B
Zone 8: Input 6 Jumper Zone 8: Input 4 ZX8 Zone 8: Input 3 Zone 8: Panel Input 3B
Zone 9: Input 7 Panel + 1 Zone 9: Input 5 Jumper Zone 9: Input 4 Zone 9: Panel Input 4B
Zone 10: Input 8 Zone 10: Input 6 Panel + 1 Zone 10: Input 5 Zone 10: Panel Input 5B
Zone 11: Input 1 Zone 11: Input 7 Zone 11: Input 6 Zone 11: Input 1
Zone 12: Input 2 Zone 12: Input 8 Zone 12: Input 7 Zone 12: Input 2
ZX8 Zone 13: Input 3 Zone 13: Input 1 Zone 13: Input 8 ZX8 Zone 13: Input 3
Jumper Zone 14: Input 4 Zone 14: Input 2 Zone 14: Input 1 Jumper Zone 14: Input 4
Panel + 9 Zone 15: Input 5 ZX8 Zone 15: Input 3 Zone 15: Input 2 Panel + 1 Zone 15: Input 5
Zone 16: Input 6 Jumper Zone 16: Input 4 ZX8 Zone 16: Input 3 Zone 16: Input 6
Zone 17: Input 7 Panel + 9 Zone 17: Input 5 Jumper Zone 17: Input 4 Zone 17: Input 7
Zone 18: Input 8 Zone 18: Input 6 Panel + 9 Zone 18: Input 5 Zone 18: Input 8
Zone 19: Input 1 Zone 19: Input 7 Zone 19: Input 6 Zone 19: Input 1
Zone 20: Input 2 Zone 20: Input 8 Zone 20: Input 7 Zone 20: Input 2
ZX8 Zone 21: Input 3 Zone 21: Input 1 Zone 21: Input 8 ZX8 Zone 21: Input 3
Jumper Zone 22: Input 4 Zone 22: Input 2 Zone 22: Input 1 Jumper Zone 22: Input 4
Panel + 17 Zone 23: Input 5 ZX8 Zone 23: Input 3 Zone 23: Input 2 Panel + 9 Zone 23: Input 5
Zone 24: Input 6 Jumper Zone 24: Input 4 ZX8 Zone 24: Input 3 Zone 24: Input 6
Zone 25: Input 7 Panel + 17 Zone 25: Input 5 Jumper Zone 25: Input 4 Zone 25: Input 7
Zone 26: Input 8 Zone 26: Input 6 Panel + 17 Zone 26: Input 5 Zone 26: Input 8
Zone 27: N/A Zone 27: Input 7 Zone 27: Input 6 Zone 27: Input 1
Zone 28: N/A Zone 28: Input 8 Zone 28: Input 7 ZX8 Zone 28: Input 2
Zone 29: N/A Zone 29: N/A Zone 29: Input 8 Jumper Zone 29: Input 3
Zone 30: N/A Zone 30: N/A Zone 30: N/A Panel + 17 Zone 30: Input 4
Zone 31: N/A Zone 31: N/A Zone 31: N/A Zone 31: Input 5
Zone 32: N/A Zone 32: N/A Zone 32: N/A Zone 32: Input 6
SP5500 No ATZ SP5500 ATZ SP6000 No ATZ SP6000 ATZ
Zone 1: Panel Input 1 Zone 1: Panel Input 1A Zone 1: Panel Input 1 Zone 1: Panel Input 1A
Zone 2: Panel Input 2 Zone 2: Panel Input 2A Zone 2: Panel Input 2 Zone 2: Panel Input 2A
Panel Zone 3: Panel Input 3 Zone 3: Panel Input 3A Panel Zone 3: Panel Input 3 Zone 3: Panel Input 3A
Zone 4: Panel Input 4 Zone 4: Panel Input 4A Zone 4: Panel Input 4 Zone 4: Panel Input 4A
Zone 5: Panel Input 5 Panel Zone 5: Panel Input 5A Zone 5: Panel Input 5 Zone 5: Panel Input 5A
Zone 6: Input 1 Zone 6: Panel Input 1B Zone 6: Panel Input 6 Zone 6: Panel Input 6A
Zone 7: Input 2 Zone 7: Panel Input 2B Zone 7: Panel Input 7 Zone 7: Panel Input 7A
ZX8 Zone 8: Input 3 Zone 8: Panel Input 3B ZX8 Zone 8: Panel Input 8 Panel Zone 8: Panel Input 8A
Jumper Zone 9: Input 4 Zone 9: Panel Input 4B Zone 9: Input 1 Zone 9: Panel Input 1B
Panel + 1 Zone 10: Input 5 Zone 10: Panel Input 5B Zone 10: Input 2 Zone 10: Panel Input 2B
Zone 11: Input 6 Zone 11: Input 1 ZX8 Zone 11: Input 3 Zone 11: Panel Input 3B
Zone 12: Input 7 Zone 12: Input 2 Jumper Zone 12: Input 4 Zone 12: Panel Input 4B
