Magellan / Spectra SP 48
Trouble Display
- Press the [TBL] key to view the Trouble Display. Please note that the keypad can be programmed to emit a beep every 5 seconds
whenever a new trouble condition has occurred. Press the [TBL] key to stop the beeping.
- To view the sub-menu, press the corresponding key in the main menu.
Installer Function Keys
To access the Installer Function keys, press:
[
ENTER]+[INSTALLER CODE] + [MEM] = Test Report: Send the “Test Report” report code programmed in section [875] (page 41) to the
monitoring station.
[
ENTER]+[INSTALLER CODE] + [STAY] = Cancel Communication: Cancels all communication with the WinLoad software or with the
monitoring station until the next reportable event.
[
ENTER]+[INSTALLER CODE] + [SLEEP] = Answer WinLoad Software: Will force the console to answer an incoming call from the
monitoring station that is using the WinLoad software.
[
ENTER]+[INSTALLER CODE] + [BYP] = Call WinLoad Software: Will dial the PC telephone number programmed in section [915]
(page 39) in order to initiate communication with a computer using the WinLoad software.
[
ENTER]+[INSTALLER CODE] + [TBL] = Installer Test Mode: The installer test mode will allow you to perform walk tests where the siren
will squawk to indicate opened zones. Press the [
TBL] key again to exit.
Main Menu Trouble Sub-Menu Trouble Menu
[1] Wireless zone low battery [1] to [32] Zones in low battery
[2] Power trouble [1] Low/No battery on the control panel
[2] AC failure on control panel
[3] Auxiliary overload on control panel
[4] Wireless keypad AC failure
[5] Wireless keypad battery failure
[6] Wireless repeater AC failure
[7] Wireless repeater battery failure
[3] Bell trouble [1] Bell disconnect on control panel
[2] Bell overload on control panel
[4] Communication trouble [1] Telephone Line Monitoring on control panel
[2] Fail to communicate on Monitoring Telephone 1 on control panel
[3] Fail to communicate on Monitoring Telephone 2 on control panel
[4] N/A
[5] Fail to communicate on voice telephone on control panel
[6] Fail to communicate with PC on control panel
[9] GSM no service (GSM network failure)
[STAY] GSM RF jamming
[5] Tamper and zone wiring failure [1] to [32] Zones in tamper and zone wiring failure
[6] Module tamper trouble [1] 2WPGM
[2] Keypad bus
[3] ZX8 bus module
[4] RTX3 bus module
[5] Wireless keypad
[7] Fire loop trouble [1] to [32] Zones in fire loop trouble
[8] Timer loss
[9] Wireless zone supervision loss [1] to [32] Zones in supervision lost
[
STAY] RF jamming trouble
[0 (10)] or [10] Module supervision loss [1] 2WPGM
[2] Keypad bus (Panel reset will not clear this trouble, clear it in
section [955])
[3] ZX8 bus module
[4] RTX3 bus module
[5] Wireless keypad supervision failure
[6] Wireless repeater supervision failure
[7] N/A
[8] VDMP3
[9] GSM module
[16] Keypad fault (K32 / K32RF / K32IRF / K32I only)
[17] Upgrade panel to V3.2 or higher (K32IRF only)
[
SLEEP] Keypad fault (K636 / K10V/H only)
