Paradox Magellan MG5050 User Manual

Magellan / Spectra SP 36
Programmable Output Options
PGM 1
[261]
PGM 2
[262]
PGM 3
[263]
PGM 4
[264]
Option OFF ON OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec, On=Min)
 N  N  N  N
[2] PGM State (Off=N.O., On=N.C.)
 N  N  N  N
[3] PGM Supervision
N  N  N  N 
[4] PGM Activation Mode (Off=Steady, On=Pulse)
 N  N  N  N
[5] PGM Pulse once every 30 seconds if armed
 N  N  N  N
[6] PGM Pulse on any alarm
 N  N  N  N
[7]
PGM Pulse on any alarm
(OFF= Partition 1, On= Partition 2)
 N  N  N  N
[8] N/A N/A N/A N/A N/A N/A N/A N/A N/A
PGM 5
[265]
PGM 6
[266]
PGM 7
[267]
PGM 8
[268]
Option OFF ON OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec., On=Min.)
 N  N  N  N
[2] PGM State (Off=N.O., On= N.C.)
 N  N  N  N
[3] PGM Supervision
N  N  N  N 
[4] PGM Activation Mode (Off=Steady, ON=Pulse)
 N  N  N  N
[5] PGM Pulse once every 30 seconds if armed
 N  N  N  N
[6] PGM Pulse on any alarm
 N  N  N  N
[7]
PGM Pulse on any alarm
(OFF= Partition 1, On= Partition 2)
 N  N  N  N
[8] N/A N/A N/A N/A N/A N/A N/A N/A N/A
PGM 9
[269]
PGM 10
[270]
PGM 11
[271]
PGM 12
[272]
Option OFF ON OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec, On=Min)
 N  N  N  N
[2] PGM State (Off=N.O., On=N.C.)
 N  N  N  N
[3] PGM Supervision
N  N  N  N 
[4] PGM Activation Mode (Off=Steady, On=Pulse)
 N  N  N  N
[5] PGM Pulse once every 30 seconds if armed
 N  N  N  N
[6] PGM Pulse on any alarm
 N  N  N  N
[7]
PGM Pulse on any alarm
(OFF= Partition 1, On= Partition 2)
 N  N  N  N
[8] N/A N/A N/A N/A N/A N/A N/A N/A N/A

Paradox Magellan MG5050 Specifications

General

Partitions	2
User Codes	32
Event Buffer	256
Built-in Transceiver	Yes
Remote Control	Yes
Wireless Keypads	Yes
StayD Mode	Yes
Remotes	Up to 32
Power Supply	16.5 VAC
Zones	32
Battery Backup	7Ah
