Paradox Magellan MG5050 User Manual

37 Programming Guide
Programmable Output Delays
Programmable Output Serial Numbers
To delete a wireless PGM, enter [000000] in its respective section.
To view the serial number display, refer to section [960].
For automatic assignment, press the PGM’s anti-tamper switch while in the respective section.
Refer to the Installer Quick Menu on page 65 for alternate PGM programming.
PGM 13
[273]
PGM 14
[274]
PGM 15
[275]
PGM 16
[276]
Option OFF ON OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec, On=Min)
 N  N  N  N
[2] PGM State (Off=N.O., On=N.C.)
 N  N  N  N
[3] PGM Supervision
N  N  N  N 
[4] PGM Activation Mode (Off=Steady, On=Pulse)
 N  N  N  N
[5] PGM Pulse once every 30 seconds if armed
 N  N  N  N
[6] PGM Pulse on any alarm
 N  N  N  N
[7]
PGM Pulse on any alarm
(OFF= Partition 1, On= Partition 2)
 N  N  N  N
[8] N/A N/A N/A N/A N/A N/A N/A N/A N/A
Section MG5000/SP5500/SP6000 Data Default = 005 MG5050/SP7000 Data Default = 005
[281] PGM 1*†: ___/___/___ (000 to 255 x 1 sec./mins.) ___/___/___ (000 to 255 x 1 sec./mins.)
[282]:PGM 2*†: ___/___/___ (000 to 255 x 1 sec./mins.) ___/___/___ (000 to 255 x 1 sec./mins.)
[283]: PGM 3†: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (000 to 255 x 1 sec./mins.)
[284]:PGM 4†: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (000 to 255 x 1 sec./mins.)
[285] PGM 5**: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[286] PGM 6: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[287] PGM 7: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[288] PGM 8: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[289] PGM 9: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[290] PGM 10: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[291]: PGM 11: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[292] PGM 12: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[293] PGM 13: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[294] PGM 14: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[295] PGM 15: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
[296] PGM 16: ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.) ___/___/___ (001 / 005 / 015 / 030 x 1 sec./mins.)
* = hardwired - MG5000 / SP5500 / SP6000 † = hardwired - MG5050 / SP6000 (optional) / SP7000
** = on-board relay - SP6000 (optional) / SP7000
Section Wireless PGM Serial Number Section Wireless PGM Serial Number
[301] PGM 1: ____/____/____/____/____/____ [309] PGM 9: ____/____/____/____/____/____
[302] PGM 2: ____/____/____/____/____/____ [310] PGM 10: ____/____/____/____/____/____
[303] PGM 3: ____/____/____/____/____/____ [311] PGM 11: ____/____/____/____/____/____
[304] PGM 4: ____/____/____/____/____/____ [312] PGM 12: ____/____/____/____/____/____
[305] PGM 5: ____/____/____/____/____/____ [313] PGM 13: ____/____/____/____/____/____
[306] PGM 6: ____/____/____/____/____/____ [314] PGM 14: ____/____/____/____/____/____
[307] PGM 7: ____/____/____/____/____/____ [315] PGM 15: ____/____/____/____/____/____
[308] PGM 8: ____/____/____/____/____/____ [316] PGM 16: ____/____/____/____/____/____
