Magellan / Spectra SP 38
Wireless PGM Signal Strength
To view the wireless PGM signal strength, press the wireless PGM’s anti-tamper switch while in the respective section.
Programmable Output Recognition
A Wireless PGM module can be assigned to any PGM. It will work in parallel with the Control Panel Output.
Section Section
[321] PGM 1 Wireless PGM Signal Strength [329] PGM 9 Wireless PGM Signal Strength
[322] PGM 2 Wireless PGM Signal Strength [330] PGM 10 Wireless PGM Signal Strength
[323] PGM 3 Wireless PGM Signal Strength [331] PGM 11 Wireless PGM Signal Strength
[324] PGM 4 Wireless PGM Signal Strength [332] PGM 12 Wireless PGM Signal Strength
[325] PGM 5 Wireless PGM Signal Strength [333] PGM 13 Wireless PGM Signal Strength
[326] PGM 6 Wireless PGM Signal Strength [334] PGM 14 Wireless PGM Signal Strength
[327] PGM 7 Wireless PGM Signal Strength [335] PGM 15 Wireless PGM Signal Strength
[328] PGM 8 Wireless PGM Signal Strength [336] PGM 16 Wireless PGM Signal Strength
Signal Strength Indicator
8 to 10 / 3 beeps = Best signal 5 to 7 / 2 beeps = Average signal 1 to 4 / 1 beep = Weak signal (Relocate)
MG5000/SP5500/SP6000 MG5050/SP7000
PGM 1 Control Panel Output 1 Control Panel Output 1
PGM 2 Control Panel Output 2 Control Panel Output 2
PGM 3 N/A Control Panel Output 3
PGM 4 N/A Control Panel Output 4
PGM 5 N/A Control Panel Relay
PGM 6 ZX8 ID= 1 Output ZX8 ID= 1 Output
PGM 7 ZX8 ID= 2 Output ZX8 ID= 2 Output
PGM 8 ZX8 ID= 3 Output ZX8 ID= 3 Output
PGM 9 PGM 9: (PGM4 output 1) PGM 9: (PGM4 output 1)
PGM 10 PGM 10: (PGM4 output 2) PGM 10: (PGM4 output 2)
PGM 11 PGM 11: (PGM4 output 3) PGM 11: (PGM4 output 3)
PGM 12 PGM 12: (PGM4 output 4) PGM 12: (PGM4 output 4)
PGM 13 RTX3 Output 1 RTX3 Output 1
PGM 14 RTX3 Output 2 RTX3 Output 2
PGM 15 RTX3 Output 3 RTX3 Output 3
PGM 16 RTX3 Output 4 RTX3 Output 4
