Paradox Magellan MG5050 User Manual

9 Programming Guide
Remote Control Button Assignment
REM1 REM2
RAC1 RAC2
* Buttons are programmed using
the Button Options Table below.
Default data*: 1 B C disabled
REM3 PGM1
[9]
PGM2
[0]
PGM3
[x]
PGM4
[3]
PGM5
[ ]
PGM6
[ ]
PGM3&4
[x] + [3]
PGM5&6
[ ] + [ ]
Default data*: B C D E 5 6 disabled disabled
[610]
All RCs
______ ______ ______ ______ ______ ______ ______ ______
RC#
IMPORTANT: When section [610] is accessed, the panel will copy the saved value of that section to all remotes.
[611] 1 ______ ______ ______ ______ ______ ______ ______ ______
[612] 2 ______ ______ ______ ______ ______ ______ ______ ______
[613] 3 ______ ______ ______ ______ ______ ______ ______ ______
[614] 4 ______ ______ ______ ______ ______ ______ ______ ______
[615] 5 ______ ______ ______ ______ ______ ______ ______ ______
[616] 6 ______ ______ ______ ______ ______ ______ ______ ______
[617] 7 ______ ______ ______ ______ ______ ______ ______ ______
[618] 8 ______ ______ ______ ______ ______ ______ ______ ______
[619] 9 ______ ______ ______ ______ ______ ______ ______ ______
[620] 10 ______ ______ ______ ______ ______ ______ ______ ______
[621] 11 ______ ______ ______ ______ ______ ______ ______ ______
[622] 12 ______ ______ ______ ______ ______ ______ ______ ______
[623] 13 ______ ______ ______ ______ ______ ______ ______ ______
[624] 14 ______ ______ ______ ______ ______ ______ ______ ______
[625] 15 ______ ______ ______ ______ ______ ______ ______ ______
[626] 16 ______ ______ ______ ______ ______ ______ ______ ______
[627] 17 ______ ______ ______ ______ ______ ______ ______ ______
[628] 18 ______ ______ ______ ______ ______ ______ ______ ______
[629] 19 ______ ______ ______ ______ ______ ______ ______ ______
[630] 20 ______ ______ ______ ______ ______ ______ ______ ______
[631] 21 ______ ______ ______ ______ ______ ______ ______ ______
[632] 22 ______ ______ ______ ______ ______ ______ ______ ______
[633] 23 ______ ______ ______ ______ ______ ______ ______ ______
[634] 24 ______ ______ ______ ______ ______ ______ ______ ______
[635] 25 ______ ______ ______ ______ ______ ______ ______ ______
[636] 26 ______ ______ ______ ______ ______ ______ ______ ______
[637] 27 ______ ______ ______ ______ ______ ______ ______ ______
[638] 28 ______ ______ ______ ______ ______ ______ ______ ______
[639] 29 ______ ______ ______ ______ ______ ______ ______ ______
[640] 30 ______ ______ ______ ______ ______ ______ ______ ______
[641] 31 ______ ______ ______ ______ ______ ______ ______ ______
[642] 32 ______ ______ ______ ______ ______ ______ ______ ______
+
+
[SLEEP] - Empty / Button disabled
[1] - Regular / Regular Force arming
[2] - Stay / Stay Force arming
[3] - N/A
[4] - Sleep / Sleep Force arming
[5] - PGM Activation (Event Group 22)*
[6] - PGM Activation (Event Group 23)*
[7] - Activate window mode (StayD)
[8] - Panic 1
[9] - Panic 2
[A] - Panic 3
[B] - PGM Activation (Event Group #8)*
[C] - PGM Activation (Event Group #9)*
[D] - PGM Activation (Event Group #10)*
[E] - PGM Activation (Event Group #11)*
[F] - Paramedic alarm
* See PGM Programming on page 31.
Button Options Table (refer to Decimal and Hexadecimal Values on page 47)
The disarm button ( ) cannot be
modified.
Remote Controls Supported:
REM1 / REM2 / RAC1
RAC2 / REM3

Paradox Magellan MG5050 Specifications

General

Partitions	2
User Codes	32
Event Buffer	256
Built-in Transceiver	Yes
Remote Control	Yes
Wireless Keypads	Yes
StayD Mode	Yes
Remotes	Up to 32
Power Supply	16.5 VAC
Zones	32
Battery Backup	7Ah
