Paradyne COMSPHERE 3610 - Page 65

Data Service Unit Menu
A-53610-A2-GB46-60 December 1996
Table A-1
(2 of 2)
Factory Default DSU Configuration Option Settings
Gen
FacC
Control
FacT
Tributary
FacB
Digital Bridge
MPTC Multipoint
Control
MPTT Multipoint
Tributary
DTE Port EIA232 EIA232 EIA232 EIA232 EIA232
RTS Control FrcOn DTE FrcOn FrcOn DTE
CTS Control Std Std Std Std Std
AntiStream Disable Disable Disable Disable Disable
LSD Lead Std Std Std Std Std
CTS Lead Std Std Std Std Std
DSR ForceOn Enable*** Enable*** Enable Enable*** Enable***
SystemStatus Enable Enable Disable Enable Enable
DSR on Test Enable Enable Enable Enable Enable
Circuit Assurance Disable Disable Disable Disable Disable
Test Pattern Std Std Std Std Std
RespondRDL Disable Enable Disable Disable Enable
LL by DTE Disable Disable Disable Disable Disable
RL by DTE Disable Disable Disable Disable Disable
Bilateral Loopback Disable Disable Disable Disable Disable
External Leads Rate Rate Rate Rate Rate
CCN by ExtLeads Disable Disable Disable Disable Disable
DTR Alarm Disable Disable Disable Disable Disable
SW Version Normal Normal Normal Normal Normal
AnswerExternalBU Disable Disable Disable Disable Disable
RLSD in MCMP No No No No No
Async→Sync
Disable Disable Disable Disable Disable
AsyncBit/Character 8 8 8 8 8
Stop Bits 1 1 1 1 1
Overspeed 2.3 2.3 2.3 2.3 2.3
PowerOnTest Enable Enable Enable Enable Enable
*** DBM- X defaults to Disable.
