COMSPHERE 3600 Series Data Service Units
A-4 December 1996 3610-A2-GB46-60
Table A-1
(1 of 2)
Factory Default DSU Configuration Option Settings
DSU
FacC
Control
FacT
Tributary
FacB
Digital Bridge
MPTC Multipoint
Control
MPTT Multipoint
Tributary
Rate(Kbps) Auto* Auto* Auto Auto* Auto*
PrtSp(Kbps) 9.6 kbps 9.6 kbps 9.6 kbps 9.6 kbps 9.6 kbps
TxClockSource DDS DDS DDS DDS DDS
Message Clamp Enable Enable Enable Enable Enable
TxElasticStore Disable Disable Disable Disable Disable
RxElasticStore Disable Disable Disable Disable Disable
19.2 PowerLevel +6 +6 +6 +6 +6
64KScrambling Off Off Off Off Off
64KLatchLoopback On On On On On
Network Interface Disable Disable Disable Disable Disable
Network Int. Timing NetI NetI NetI NetI NetI
V.54 LoopBack Disable Disable Disable Disable Disable
Diag DSU FacC FacT FacB MPTC MPTT
Diagnostic Type Disruptive Disruptive Disruptive NonDisruptive NonDisruptive
2ndChannel(bps) 400 400 400 400 400
Disruptive Type 3600e 3600e 3600e 3600e 3600e
Diag Gen FacC FacT FacB MPTC MPTT
Position Control Trib Control Control Trib
LinkConfiguration Point-to-Point** Point-to-Point** Multipoint Multipoint Multipoint
Response Period 1 1 1 1 1
TributaryTimeOut 0:10 0:10 0:10 0:10 0:10
Diagnostic Connection CC CC CC CC CC
Link Delay 0s 0s 0s 0s 0s
Network Delay 0s 0s 0s 0s 0s
Packet Delay 0s 0s 0s 0s 0s
Extend Channel No No No No No
Upstream Port Port 1 Port 1 Port 1 Port 1 Port 1
M-PtSymPort Disable Disable Disable Enable Enable
Fast Select Enable Enable Enable Enable Enable
LPDA-2 FacC FacT FacB MPTC MPTT
LPDA-2 Disable Disable Disable Disable Disable
LPDA Address 1 1 1 1 1
SNA Backup Disable Disable Disable Disable Disable
Code 1 Model 3610 582210 582210 582210 582210 582210
Model 361 1 582218 582218 582218 582218 582218
Code 2 Model 3610 5822101 5822101 5822101 5822101 5822101
Model 361 1 5822181 5822181 5822181 5822181 5822181
* Defaults to 56 kbps when MCMP installed.
** Defaults to Multipoint when MCMP installed.
