echnical Specifications
F-33610-A2-GB46-60 December 1996
Table F-3
(2 of 3)
General COMSPHERE 3600 Series Technical Specifications
Specifications Criteria
APPROVALS
FCC Part 15
FCC Part 68
UL
3610 DSU
3611 DSU, 3000 Series Carrier
CSA
Safety
3610 DSU
3611 DSU, 3000 Series Carrier
Emissions
Bell Canada
Class A digital device
AW292J-61661-DD-N
Listed UL 1950
Recognized Component UL 1950
Certified CSA 22.2, No. 220-M1986
Certified Component CSA 22.2, No. 950-M89
Class A digital apparatus
“DCTE Specifications,” July 1989, Issue 1
DTE INTERFACE
3610 and Non-modular 3611 DSUs
25-pin D-subminiature connector
34-pin connector
Modular 361
1 DSU
25-Pin V.35 Interface
Uses a Rear Connector Plate with two
25-pin D-subminiature connectors.
EIA-232/ ITU V.24 (ISO 2110)
ITU V.35 (ISO 2593)
EIA-232/ ITU V.24 (ISO 2110)
ITU V.35 (ISO 2593)
A modular DSU V.35 interconnect cable is required to use the V.35
connector. The cable provides an interface between the DSU’s 25-pin
D-type connector and the DTE cable’s V.35 connector.
ENVIRONMENT
Operating Temperature
Storage Temperature
Relative Humidity
Shock and Vibration
32°
to 122
° F (0°
to 50
° C)
–4°
to 158
° F (–20°
to 70
° C)
5%—95% (noncondensing)
Withstands normal shipping and handling
HEAT DISSIPATION (MAX.) AT 115 VAC
3610 DSU
3610 DSU with DBM
3611 DSU
3611 DSU with DBM
3000 Series Carrier (16 DSUs with DBMs
plus SDU and fan module)
22.16 Btu/hr.
29.00 Btu/hr.
22.16 Btu/hr.
27.30 Btu/hr.
563.00 Btu/hr.
NMS COMPATIBILITY DATAPHONE II System Controller, Diagnostic Console, or
Network Controller
COMSPHERE 6700 Series NMS, Release 4.0 or greater for full support
COMSPHERE 6800 Series NMS, Release 4.1.5 or greater for full support
NetView, Version 1, Release 3 or greater
ASYNC TERMINAL ANSI X3.64/VT100 compatibility
Data Rate: 9.6 kbps
8 bits per character, 1 stop bit, no parity
