Compax3F device description
192-121100 N7 December 2010
13
In diesem Kapitel finden Sie
State of delivery ............................................................................................................... 13
Plug and connector assignment Compax3 Fluid .............................................................. 13
3.1 State of delivery
Compax3 is delivered without configuration!
After switching on the 24VDC supply, the red LED is flashing while the green LED
is dark.
Please configure the device with the help of the Windows-Software "Compax3
ServoManager"!
3.2 Plug and connector assignment Compax3 Fluid
In diesem Kapitel finden Sie
Meaning of the front panel LEDs (via X10)....................................................................... 13
Plug and connector assignment ....................................................................................... 14
Plug and connector assignment complete........................................................................ 15
Analog Input (plug X1) ..................................................................................................... 16
Analog Output (plug X2) .................................................................................................. 17
Voltage supply (plug X3) .................................................................................................. 18
RS232/RS485 interface (plug X10) .................................................................................. 19
Analog / Encoder (plug X11) ............................................................................................ 20
Digital inputs/outputs (plug X12) ...................................................................................... 21
Feedback (connector X13)............................................................................................... 22
Mounting and dimensions ................................................................................................ 23
3.2.1. Meaning of the front panel LEDs (via X10)
Status
LED
red
LED
green
Voltages missing. off off
While booting. alternately flashing
No configuration present.
Compax3 IEC61131-3 program not compatible with Compax3 Firmware.
no Compax3 IEC61131-3 program.
flashing off
Axis(es) blocked. off flashes slowly
Axis(es) enabled. off on
Axis in fault status / fault present. on off
3. Compax3F device description
