Technical Characteristics Hydraulics Controller
24
192-121100 N7 December 2010
Voltage supply 24VDC
Controller type Compax3 F001 D2
Voltage range
21 - 27VDC
Mains module
with switch-on current limitation, due to
capacitive load
Fuse
MTP miniature circuit breaker or "delayed action
fuse", due to capacitive load
Current drain of the device
0.8A (max. 1.5A)
Total current drain
0.8A + total load of the digital outputs
Ripple
<1Vss
Requirement according to safe extra
low voltage (SELV)
yes
Size / weight
Controller type Compax3 F001 D2
Dimensions: HxWxD [mm]
199x80x130
Weight [kg]
2.0
Housing / protection class
Enclosed metal housing, insulation according to
EN60529 / IP 20
Inputs and outputs
Controller type
Compax3 F001 D2
8 control inputs
24VDC / 10kOhm
4 control outputs
Active HIGH/short-circuit protected, 24V /
100mA
4 analog current inputs
14Bit
2 analog voltage inputs
14Bit
4 analog outputs
16bits, current or voltage
2 analog monitor outputs
8bits
COM ports
RS232

115200 baud
 Word length: 8 bits, 1 start bit, 1 stop bit

Hardware handshake XON, XOFF
RS485 (2 or 4-wire)

9600, 19200, 38400, 57600 or 115200
baud
 Word length 7/8 bit, 1 start bit, 1 stop bit
 Parity (can be switched off) even/odd

2 or 4-wire
Supported valves and feedback systems
Valves

D1*FH series
Absolute encoder

Analog 0..20mA, 4..20mA, ±10V
 Start/Stop - interface
 SSI interface
 EnDat 2.1-interface
 1VSS (max. 400kHz) Interface, 13.5bits /
graduation of the scale
 RS422 Encoder (max. 5MHz, (track A or
B) internal resolution quadrature
