Parker Compax3 Fluid - Plug and Connector Assignment

Compax3F device description Hydraulics Controller
14
192-121100 N7 December 2010
3.2.2. Plug and connector assignment
X1
Analog Inputs
X2
Analog Outputs
X3
24 VDC power supply
X10
RS232/RS485
X11
2. Feedback Type
X12
Inputs/Outputs
X13
1. Feedback Type
Caution!
Always switch devices off before wiring them!
