10
PHD
Connectors
PHD50 J2 Connector Pinout
Pin
Function
1
GPIO10 (digital or frequency input)
2
GPIO9 (digital or frequency input)
3
NC
4
NC
5
NC
6
VIDEO1_GND
7
VIDEO1
8
NC
9
Ground
10
P12V0 (12V regulated supply)
11
Ground
12
Ground
13
GPIO8 (analog input)
14
P5V0 (5V sensor supply)
15
RS232-RX (debugging use only)
16
RS232-TX (debugging use only)
17
NC
18
NC
19
NC
20
NC
17
19
Table of Contents
Default Chapter
3
Table of Contents
3
Publication History
5
Safety
6
Safety Symbols
6
General Safety Regulations
6
Welding after Installation
7
Construction Regulations
7
Safety During Installation
7
Safety During Start-Up
8
Safety During Maintenance and Fault Diagnosis
8
1 About the PHD (Parker Hannifin Display)
9
Diagram Conventions
13
2 Connectors
15
Pinouts
16
3 Inputs
21
PHD28 Inputs
21
PHD50 Inputs
22
PHD70 Inputs
23
PHD28/PHD50 Analog Input Capabilities
24
PHD28/PHD50/PHD70 Digital Input Capabilities
26
PHD50/PHD70 Frequency Input Capabilities
28
Using Inputs as Low Power Outputs
30
Low Power, High-Side Output Capabilities
30
4 Outputs
32
PHD28/PHD50/PHD70 Low-Side Outputs
32
Low-Side Output Capabilities
32
Sensor and Regulated Supply Outputs
34
Sensor and Regulated Supply Capabilities
35
5 Power
36
6 Communication
37
Controller Area Network
37
CAN Capabilities
37
PHD CAN Installation Connections
38
Usb
40
7 HMI (Human Machine Interface)
41
Ambient Light Sensor
41
Touchscreen
41
Keypad
41
Buzzer
41
Video
42
Video Input Capabilities
42
8 Serial Ethernet Recovery Flexcan (SERF) Development Board
43
SERF Overview
43
Available Inputs and Outputs
44
Switches and Connectors
45
Jumpers
46
DB9 Pinout Reference
49
9 Mounting the PHD
50
Dimensions
51
Phd28
51
Phd50
52
Phd70
53
10 Understanding PHD Software
54
11 Environmental Protection
55
Emi
55
Mechanical Environment
55
Esd
55
Climate Environment
55
Chemical Environment
56
12 Index
57
