3 Connectors and terminal boards
Note: if there isn’t corrispondence between the label on the drive and this manual, please
contact the service department.
3.1 SPD 2, 5 and 8
Power terminal connections SPD2, SPD5 and SPD8
1 L1
2 L2
3 L3
LINE
4 Earth I
5 U-I
6 V-I
7 W-I
MOTOR
8 Earth II
9 U-II
10 V-II
11 W-II
N. C.
12 +B
13 IR
14 CB
15 -B
BUS CONFIGURATION
AND BREAKING RESISTOR
Signal terminal connections (X4)
1 AUX Ref. + (AN1+) Analogue Ref. + (+REF) 25
2 AUX Ref. – (AN1-) Analogue Ref. – (-REF) 26
3 0VA ( shield ) 0VA ( shield ) 27
4 Vout + ECC Resolver 28
5 0VA ( shield ) - ECC Resolver 29
6 IN0 + SIN Resolver 30
7 IN1 - SIN Resolver 31
8 IN2 + COS Resolver 32
9 IN3 - COS Resolver 33
10 0VQ ( 0V panel ) 0VA ( shield ) 34
11 OUT0 + PTC 35
12 OUT1 - PTC 36
13 +A ENCODER OUT +A ENCODER IN 37
14 -A ENCODER OUT -A ENCODER IN 38
15 +B ENCODER OUT +B ENCODER IN 39
16 -B ENCODER OUT -B ENCODER IN 40
17 +C ENCODER OUT +C ENCODER IN 41
18 -C ENCODER OUT -C ENCODER IN 42
19 0VQ ( 0V panel ) 0VE ( 0V ENCODER ) 43
20 +SR + DRIVE ENABLE + CK 44
21 -SR - DRIVE ENABLE - CK 45
22 SC-A FEEDBACK + 5VE (SUPPLY ENCODER ) 46
23 SC-B FEEDBACK 0VE ( 0V ENCODER ) 47
24 0VQ 0V POWER SUPPLY +24V IN POWER SUPPLY 48
