Parker Hannifin S.p.A. - Divisione S.B.C. “SPD” User’s Manual
8
1.5 Support tools
To simplify the drive configuration in motion-control applications, a software package is
provided to be installed on a personal computer (PC), which implements a serial
communication with the drive.
1.6 Conformity to EMC standards
Immunity:
EN50082-1* / EN61000-6-2 Basic immunity specifications
CEI - EN61800-3 Product standard: Variable speed electric
drives, includes:
Immunity for electrostatic charge
Immunity for electromagnetic field
Immunity for fast transient burst Emission:
EN50081-1* / EN61000-6-4 Basic specifications for radio interference
CEI - EN61800-3 Product standard
In order to conform with the standards, installation must be carried out as explained in chapter
“Installation and safety instructions”.
1.7 Safety
Safety rules EN60065,EN50178
Low voltage regulation 73/23/CEE modified by 93/68/CEE
Applied regulation EN60204-1
This is a product of the restricted sales distribution class according to EN61800-3.
Ina domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.
1.8 Data for the UL certification
The drive could be installed in the environments of type: Pollution degree 2, like suitable
from the UL norm 508C, Par. 35.9.4a1.
Data of the braking resistance:
Max current [Amps]
DRIVE
Peak Rms
Max Duty Cycle
[%]
Power
[W]
Min resistance D.B.U.
[Ω]
SPD2,5,8 20 0,15 0,75 120 40
