3.2 SPD 16 e 25
Power terminal connections (X4) SPD16 and SPD25
1 L1
2 L2
3 L3
LINE
4 Earth
5 U
6 V
7 W
MOTOR
8 +C
9 +B
10 IR
11 CB
12 -B
BUS CONFIGURATION
AND BREAKING RESISTOR
CAN bus (X2)
(DB9 male)
N. Pin Signal Description
1 n.c.
2 CAN_L Low communication line
3 CAN_GND CAN ground
4 n.c.
5 CAN_SHLD Optional screen connection
6 GND Optional CAN ground
7 CAN_H High communication line
8 n.c.
9 n.c.
Serial 422 / 485 (X3)
(DB9 female)
N. Pin Signal
1 TX
2 RX
3 /TX
4 /RX
5
6 +BR
7 -BR
8 0 V
9 0 V
