MIC 1161 Manual
26
3.1.8 ANNUNCIATOR
An additional (optional) annunciator output is available. If selected in Pro-
gram mode (either for USE2 or USE3) the annunciator output operates as
follows:
If the limit is, or has been, exceeded AND the Reset key has NOT been
pressed since the limit was exceeded, then the annunicator output will be
active.
During the condition when the annunciator output is active, the EXCEED
indicator will be flashing.
If the Reset key is pressed while the limit is exceeded, the EXCEED indica-
tor will change to ON steady and the annunciator output is inactive. Subse-
quently, when the limit is not exceeded, the EXCEED indicator will go off.
3.1.9 REMOTE RESET (optional)
The Remote Reset option allows a dry contact closure to substitute for the
front panel Reset switch. Operation is as follows:
If the option "rrES" (remote reset) is selected then:
A contact closure will simulate the action of the front panel reset
switch.
A contact opening will have no effect.
If the external contacts are left closed, only ONE reset operation will occur.
If the instrument subsequently goes into a state where reset is required
again, the contacts must be opened and closed again. The front panel
Reset switch can still be used to action a reset if required.
Configuration 3.2
All configurable parameters are provided in Tables 3-1 through 3-3 on the
following pages. These tables illustrate the display sequence, parameter
adjustment and factory setting for each step.
Depression of the SCROLL key will cycle the display (if alarms are not
active) to the "Loc" feature where, after entering the correct code, the dis-
play cycles through all enabled modes as follows:
