Partlow MIC 1161 - Logical and of Alarm 1 with Alarm 2; Decimal Point; Engineering Units Upper; Engineering Units Lower

MIC 1161 Manual
34
Logical AND of Alarm 1 with Alarm 2
Direct-Acting Reverse-Acting
AL-1 OFF, AL-2 OFF: Relay OFF AL-1 OFF, AL-2 OFF: Relay ON
AL-1 ON, AL-2 OFF: Relay OFF AL-1 ON, AL-2 OFF: Relay ON
AL-1 OFF, AL-2 ON: Relay OFF AL-1 OFF, AL-2 ON: Relay ON
AL-1 ON, AL-2 ON: Relay ON AL-1 ON, AL-2 ON: Relay OFF
Decimal Point
This parameter, applicable only if a linear input is specified, defines the
position of the decimal point in values for the process variable, setpoint,
alarm levels and retransmission outputs as follows:
Value Decimal Point Position
0 XXXX
1 XXX.X
2 XX.XX
3 X.XXX
The default value is 0. Display code is dPoS.
Engineering Units Upper
This parameter, applicable only if a linear input is specified, defines the
scaled input value when the process variable input is at its maximum value.
It is adjustable between -1999 to 9999. The default value is 1000. This
parameter can be set to a value less than (but not equal to) Engineering
Units Lower, in which case the sense of the input is reversed. Display code
is Euu.
Engineering Units Lower
This parameter, applicable only if a linear input is specified, defines the
scaled input value when the process variable input is at its minimum value.
It is adjustable between -1999 and 9999. The default value is 0. This pa-
rameter can be set to a value greater than (but not equal to) Engineering
Units Upper, in which case the sense of the input is reversed. Display code
is EuL.
Maximum Hold
This parameter tracks and saves the maximum excursions of the process
variable, applicable to a High Limit only. This is a Read Only parameter.
Display code is HiHd.
