MIC 1161 Manual
44
Output Specifications
Limit Switch Output 1
Type: Relay
Contact Type: Single Pole/Double Throw (SPDT)
Rating: 5A resistive at 120/240V AC
Lifetime: > 100,000 operations at rated voltage/current
Isolation: Inherent
OUTPUT 2 (Alarm or Annunciator)
Type: Relay
Contact Type: Single Pole/Double Throw (SPDT)
Rating: 2A resistive at 120/240V AC
Lifetime: > 500,000 operations at rated voltage/current
Isolation: Inherent
OUTPUT 3 (Alarm, Annunciator, or Retransmit)
Type: Relay or DC linear (retransmit only)
Relay
Contact Type: Single Pole/Double Throw (SPDT)
Rating: 2A resistive at 120/240V AC
Lifetime: > 500,000 operations at rated voltage/current
Isolation: Inherent
Retransmit
Resolution: Eight bits in 250ms (10 bits in 1000 ms typical, >10
bits in >1000 ms typical).
Update Rate: 4/sec.
Ranges: 0-20mA, 4-20mA, 0-10V, and 0-5V
Load Impedance: 0-20mA: 500 ohm maximum
4-20mA: 500 ohm maximum
0-10V: 500 ohm minimum
0-5V: 500 ohm minimum
Isolation: Isolated from all other inputs and outputs.
