FIGURE B-2 CPU PWA
JU1
JU3
JU2
JU1
RTD
DC
(mV)
T/C
DC
(mA)
DC
(V)
Input Conditioning Jumper
JU2
Output Type Jumper
JU3
RELAY
RELAY
