Partner SP-600-A - Figure 1.4 SP-600-A I;O Connectors

4 CHAPTER 1 GETTING STARTED
I/O connectors
Connector Description
1 VGA port
2 COM 1 port
3 USB ports
4 RJ11 cash drawer port
5 DC 12V input connector
6 DC 12V output connector
7 COM 3 port
8 COM 2 port
9 LAN jack
10 SATA cable hole
521 3 4
6
7 8 9
10
Figure 1.4 SP-600-A I/O connectors
