Partner SP-600-A - Heatsink

61
Heatsink
Before proceeding, remove
the following FRUs.
• “SP-600-A Panel” on
page 57.
• “Panel Back Cover” on
page 58.
1. Remove ten screws from
the het sink.
2. Remove the heat sink.
CAUTION
To avoid the heat
sink clearance
issue. When you
replace the heat
sink, check the
thermal pads
should be stuck
between the
contact surface of
the heat sink and
chips.
