51
Figure 4.3 SP-600-A mainboard connectors
Mainboard connectors
connector to
LCD panel
connector to
MSR
connector to
SATA HDD
connector to
HDD power
connector to
speaker
connector to
touch panel
connector to
PS/2 port
connector to
parallel port
connector to
power LED
connector to
power button
connector to
power jack
