Partner SP-600-A - Connector Pin Definitions

5
15
69
Connector pin dene
This section describes the connectors pin dene.
COM connector pin dene
VGA connector pin dene
USB connector pin dene
Pin Signal Pin Signal
1 DCD 6 DSR
2 SIN 7 RTS
3 SOUT 8 CTS
4 DTR 9 RI
5 GND
1 5
6
10
11 15
Pin Signal Pin Signal Pin Signal
1 Red 6 AGND 11 N/A
2 Green 7 AGND 12 DDC DAT
3 Blue 8 AGND 13 Horizontal Sync
4 N/A 9 N/A 14 Vertical Sync
5 GND 10 GND 15 DDC CLK
14
Pin Signal
1 USB Vcc
2 USB -
3 USB +
4 USB GND
