Tape Head
1. Refer to the View Setup Values PanelView screen for scale settings.
2. Adjust the pressure sensitive tape unit according to the width of the case.
3.
Turn the adjusting handle to raise or lower the tape head to the appropriate
scale setting.
Operations Manual CE35-T Case Erector
M-CE35T-2c Horiz Mag 3/2/2010
Changeover Procedures
61
Fig. 56: Pressure Sensitive Tape Quick-Release
Handle and Scale
