Case Discharge Stop
Note: This is not a scaled adjustment.
1. Loosen the two quick-release handles.
2. Slide the stop to a position where the case is stopped and tips off easily.
3. Tighten the quick-release handles.
CE35-T Case Erector Operations Manual
3/2/2010 M-CE35T-2c Horiz Mag
62
serudecorP revoegnahC
Fig. 57: Set-up Arm Adjustment Handle
and Scale
Quick-release
Handle
Fig. 58: Case Discharge Stop
Case Discharge
Stop
Quick-Release
Handle
Quick-Release
Handle
