Tip-off Guide
Note: This is not a scaled adjustment.
1. Loosen the quick-release handles.
2. Slide the tip-off guide into the appropriate position according to the size of
the erected case.
3. Tighten the quick-release handles.
CE35-T Case Erector Operations Manual
3/2/2010 M-CE35T-2c Horiz Mag
64
serudecorP revoegnahC
Fig. 60: Tip-off Guide
Tip-off Guide
Fig. 61: Tip-Off Guide Quick-Release
Handles
