INTELLICHEM
®
Controller Installation and User’s Guide
16
ORP Menu Description (Continued)
Displays the current ORP set point value. Adjust the ORP set point to meet pool and spa
chemistry standards. The adjustable range is from 400 to 800 in increments of 10. The
default ORP set point value is 700.
To adjust the ORP set point:
Press MENU ORP Menu ORP Setpt
Press / to decrease or increase the current ORP set point value.
Note: When using IntelliChlor SCG, parameters are the same as above.
ORP Set Point
ORP Tweak
The exact reading of each individual ORP sensor can vary because of water makeup and
variances in probe condition age, etc. The ORP Tweak menu feature allows you to adjust
the ORP sensor reading to match the manual reading taken. The adjustable range is +/-
50mV. After adjusting the ORP value, the main screen should now display the same value
as the manual reading.
To adjust the ORP sensor level:
Press MENU / pH Menu  ORP Tweak
The current value is displayed (reading = x.xx). Press / to adjust the ORP sensor level
(+/- 50 mV). To remove the tweak, set the level back to 0 (zero).
ORP Supply (page 1/2)
Units: Select gal-US, gal-UK, Liters or Time (hours/minutes)*.
Chemical: Use Chlorine or Bromine.
ORP Supply (page 2/2)
Capacity: Select from 0 to 200 maximum gal-US, gal-UK, or Liters.
*Time (Reminder in: H:xxx M:xx) If the supply Units were set to Time, the Capacity
feature becomes a Reminder feature, as in an egg-timer. This can be used to trigger
an alarm, based on cumulative feed times as to when to clean the SCG plates. Set the
reminder time in hours (0-8760) and minutes (00-59) on ORP Supply page 2/2. Note:
Entering the hours and minutes time (H:00 M:00) will display the hour glass icon on the
main screen.
Level Gauge (liquid only): Displays level gauge hour when using liquid chemical doser.
Tank icon symbol is used for liquid chemical configurations that include valid supply and
doser feed rate information.
ORP Supplies
ORP Supply 1/2
Unit: USGal
Chemical:
[Chlorine]
ORP Supply 2/2
Capacity:
4.00 gal-US
Gauge: 3
ORP Supply 2/2
Reminder in:
H:1000 M:00
Gauge: 6



Pentair intellichem Specifications

General

pH Control	Yes
ORP Control	Yes
Display	LCD
Waterproof Enclosure	Yes
Enclosure Rating	NEMA 4X
Alarms	Yes
Operating Temperature	32° to 122°F (0° to 50°C)
Humidity Range	0% to 95% non-condensing
Communication	RS-485
Outputs	Relays for chemical feed pumps
Inputs	Flow sensor
