INTELLICHEM
®
Controller Installation and User’s Guide
24
ORP Control (page 1/2 - 2/2)
Hardware settings must be chosen carefully. If both dosers are assigned to the same
internal pump or external relay, the program will display an error message upon exiting
the Hardware menu.
Doser Type 1/2: Select the ORP control hardware:
- IntelliChem ORP feed method being used (INTERNAL PUMP, EXTERNAL
RELAY, INTELLICHLOR
®
Salt Chlorine Generator (SCG), NONE.
Doser Type 2/2:
- INTERNAL PUMP: Right-Side (MTR_R), Left-Side (MTR_L)
- EXTERNAL RELAY: Ex_Relay 1, Ex_Relay 2
- INTELLICHLOR: All Models (IC20, IC40, IC60)
Flow (Rate) 2/2:
- INTERNAL PUMP (MTR_R/MTR_L): FLOW: 65 GPD (gallons per day)
- EXTERNAL RELAY 1 or 2: RATE: xxx GPD (gallons per day). Note: Set
to 0 to use time-based feed instead of volumetric (only on the Ext Relays
(not internal motors).
Alarm Output Select the following the IntelliChem
®
Controller alarm output information:
- External alarm output: Ex_Relay1 or Ex_Relay2.
For an external alarm indicator, an unused relay may be selected to turn
on when the red Alarm LED on the front panel is turned on.
The alarm relay must be chosen carefully. If Ex_Relay1 or Ex_Relay2 is
used for a doser, it must not be used for an alarm output. Upon exiting the
Hardware menu, the program will check to be sure the same relay is not
used more than once. If a relay is assigned to more than one function, an
error message will be displayed.
error message:
--------------------------
Alarm Relay
conflicts with
Ext Doser Relay
Changed to Ex_R1
-------------------------- or
Changed to Ex_R2
or
Changed to N/A
