INTELLICHEM
®
Controller Installation and User’s Guide
36
Plumbing the Flow Cell (Continued)
10. Locate the chemical injection points.
11. Prepare and install the chemical injector fittings.
12. Install the chemical storage containers.
13. Turn ON the main circulation pump.
14. Check for leaks and verify the flow sensor indicates flow.
Flow Cell Inlet and Exit Lines
1. It is essential that the supply line be at a higher pressure than the
discharge line so the water will flow through the cell at a steady rate in
the right direction.
2. Inlet should be installed after filter and before heater. Note: Plumb the
INLET before the solar valve.
3. Exit should be installed after heater and as far away from any equipment
as possible.
Do not inject acid directly in to the ow cell. Injecting acid in
this way will result in incorrect reading which may damage the
existing pool equipment.
The ow switch is a dry contact only (no current). Use with any
other brand of ow switch voids WARRANTY
and UL listing.
Make sure all pumps are OFF before drilling into pipes. Never
switch ON chemical feed pumps without the pool lter pump
also running.
