Pentair IntelliChlor IC20 User Manual

6
IntelliChlor Power Center Installation Guide
Electrical Specifications and 110 VAC and 220 VAC Wiring
Circuit Protection:
Two-pole 20 AMP device at the electrical panel.
IntelliChlor Model IC20
Input: 90-130 VAC, 50/60 Hz, 220 Watts (2 AMP) or 220-240 VAC, 50/60 Hz, 220 Watts (1 AMP).
Output: 22-39 VDC @ 6 AMPS maximum from the Power Center.
Free available chlorine: 0.22 kg/ 24 hours.
220 VAC Basic System Wiring
110 VAC Basic System Wiring
IMPORTANT: When using IntelliChlor with an IntelliTouch system, it is recommended to wire
the Power Center to the pump side of the relay located in the IntelliTouch Load Center. This
method does not require a ground fault circuit-interrupter (GFCI) to protect the circuit.

Pentair IntelliChlor IC20 Specifications

General

Model	IntelliChlor IC20
Type	Salt Chlorine Generator
Pool Size	Up to 20, 000 gallons
Voltage	120/240 VAC
Power Supply	External Power Center
Flow Rate	Minimum 20 GPM
Water Temperature	50°F to 104°F (10°C to 40°C)
Cell Life	10, 000 hours
Warranty	3 years
Chlorine Output	0.7 lbs/day
