Electrical Specifications and 110 VAC and 220 VAC Wiring
Circuit Protection:
Two-pole 20 AMP device at the electrical panel. Note: Spacing of 3 mm should be met by the
all-pole disconnect.
IntelliChlor Model IC20
Input: 90-130 VAC, 50/60 Hz, 220 Watts (2 AMP) or 220-240 VAC, 50/60 Hz, 220 Watts (1 AMP).
Output: 22-39 VDC @ 6 AMPS maximum from the Power Center.
Free available chlorine: 0.22 kg/ 24 hours.
220 VAC Basic System Wiring
110 VAC Basic System Wiring
IMPORTAT: When using IntelliChlor with an IntelliTouch system, it is recommended t o wire
the Power Center to the pump side of the relay located in the IntelliTouch Load Center. This
method does not require a ground fault circuit-interrupter (GFCI) to protect the circuit.
