IntelliChlor User’s Guide
Table 2: Troubleshooting the Power Center
Problem
Possible Cause
Corrective Action
IntelliChlor unit does
not have green power
light.
Fuse in Power Center is open.
Replace AC fuse, located at bottom of Power
Center.
No AC power to Power Center.
Verify time clock is providing 110 VAC or 220
VAC to Power Center when active.
Transformer leads not wired correctly in Power
Center.
Verify transformer leads wired to AC source by
referring to wiring diagram decal on inside of
Power Center cover.
