Pentair IntelliChlor IC20 User Manual

5
IntelliChlor Power Center Installation Guide
Troubleshooting
Note: Turn off power to unit before attempting to service or repair
Problem
Possible Cause
Corrective Action
The IntelliChlor green
power light on the
control panel is not on.
Fuse in Power Center is open.
Replace 10 AMP (3AG Style) fuse, located at
bottom of Power Center.
No AC power to Power Center.
Verify time clock is providing 110 VAC or 220
VAC to Power Center when active.
Tansformer leads not wired correcly in Power
Center.
Verify transformer leads wired to AC source by
referring to wiring diagram decal on inside of
Power Center cover.

Pentair IntelliChlor IC20 Specifications

General

Model	IntelliChlor IC20
Type	Salt Chlorine Generator
Pool Size	Up to 20, 000 gallons
Voltage	120/240 VAC
Power Supply	External Power Center
Flow Rate	Minimum 20 GPM
Water Temperature	50°F to 104°F (10°C to 40°C)
Cell Life	10, 000 hours
Warranty	3 years
Chlorine Output	0.7 lbs/day
