Pentair IntelliChlor IC20 User Manual

16
IntelliChlor User’s Guide
Table 2.
Approximate Kilograms (Pounds) of Salt Needed to Maintain 3,000 PPM
Salt concentration
before addition
Salt addition required
per 3785.41 liters (1000 gallon)
pool capacity
Salt concentration
before addition
Salt addition required
per 3785.41 liters (1000 gallon)
pool capacity
0 ppm
11.6 kg (25.6 lbs)
1500 ppm
5.8 kg (12.8 lbs)
300 ppm
10.7 kg (23.5 lbs)
1800 ppm
4.8 kg (10.7 lbs)
500 ppm
9.7 kg (21.4 lbs)
2000 ppm
3.9 kg (8.5 lbs)
800 ppm
8.7 kg (19.2 lbs)
2300 ppm
2.9 kg (6.4 lbs)
1000 ppm
7.8 kg (17.1 lbs)
2500 ppm
1.9 kg (4.2 lbs)
1300 ppm
6.8 kg (15 lbs)
2800 ppm
1 kg (2.2 lbs)
Table 3.
Approximate Amount of Chlorine Stabilizer (Cyanuric Acid) Needed to Obtain 75 PPM
Pool Size Liters (gallons)
Stabilizer
Level Before
Addition
37,854
10,000
(38 m 3 )
45,425
12,000
(45 m 3 )
52,996
14,000
(53 m 3 )
60,567
16,000
(60 m 3 )
68,137
18,000
(68 m 3 )
75,708
20,000
(76 m 3 )
83,279
22,000
(83 m 3 )
90,850
24,000
(91 m 3 )
98,421
26,000
(98 m 3 )
105,992
28,000
(10 6 m 3 )
30000
30,000
(13 m 3 )
0.00 PPM
2.8 kg
(6.25 lbs)
3.4 kg
(7.50 lbs)
4 kg
(8.75 lbs)
4.5 kg
(10.0 lbs)
5 kg
(11.25lb)
5.7 kg
(12.5 lbs)
6.2 kg
(13.75 lbs)
6.8 kg
(15.0 lbs)
7.4 kg
(16.3 lbs)
7.9 kg
(17.5 lbs)
8.5 kg
(18.75 lbs)
10 PPM
2.5 kg
(5.40 lbs)
2.9 kg
(6.50 lbs)
3.5 kg
(7.60 lbs)
3.9 kg
(8.60 lbs)
4.4 kg
(9.75 lbs)
5 kg
(10.8 lbs)
5.4 kg
(11.90 lbs)
5.8 kg
(12.9 lbs)
6.3 kg
(14.0 lbs)
6.9 kg
(15.2 lbs)
7.4 kg
(16.25 lbs)
20 PPM
2 kg
(4.60 lbs)
2.5 kg
(5.50 lbs)
2.9 kg
(6.40 lbs)
3.3 kg
(7.30 lbs)
3.7 kg
(8.25 lbs)
4.1 kg
(9.20 lbs)
4.5 kg
(10.0 lbs)
4.9 kg
(10.9 lbs)
5.4 kg
(11.9 lbs)
5.8 kg
(12.8 lbs)
6.2 kg
(13.75 lbs)
30 PPM
1.7 kg
(3.75 lbs)
2 kg
(4.50 lbs)
2.4 kg
(5.25 lbs)
2.7 kg
(6.00 lbs)
3 kg
(6.75 lbs)
3.4 kg
(7.50 lbs)
3.7 kg
(8.25 lbs)
4 kg
(9.00 lbs)
4.4 kg
(9.75 lbs)
4.8 kg
(10.5 lbs)
5.3 kg
(11.75 lbs)
40 PPM
1.3 kg
(2.90 lbs)
1.6 kg
(3.50 lbs)
1.8 kg
(4.00 lbs)
2 kg
(4.60 lbs)
2.4 kg
(5.25 lbs)
2.6 kg
(5.80 lbs)
2.9 kg
(6.40 lbs)
3.1 kg
(6.90 lbs)
3.4 kg
(7.58 lbs)
3.7 kg
(8.20 lbs)
4 kg
(8.75 lbs)
50 PPM
1 kg
(2.00 lbs)
1.1 kg
(2.50 lbs)
1.3 kg
(2.90 lbs)
1.5 kg
(3.30 lbs)
1.7 kg
(3.75 lbs)
1.9 kg
(4.10 lbs)
2 kg
(4.60 lbs)
2.2 kg
(4.90 lbs)
2.4 kg
(5.40 lbs)
2.6 kg
(5.80 lbs)
2.8 kg
(6.25 lbs)
60 PPM
0.5 kg
(1.25 lbs)
0.7 kg
(1.50 lbs)
0.8 kg
(1.75 lbs)
1 kg
(2.00 lbs)
1 kg
(2.25 lbs)
1.1 kg
(2.50 lbs)
1.2 kg
(2.75 lbs)
1.4 kg
(3.00 lbs)
1.5 kg
(3.25 lbs)
1.6 kg
(3.50 lbs)
1.7 kg
(3.75 lbs)
70 PPM
0.2 kg
(0.40 lbs)
0.2 kg
(0.50 lbs)
0.3 kg
(0.60 lbs)
0.3 kg
(0.66 lbs)
0.3 kg
(0.75 lbs)
0.4 kg
(0.80 lbs)
0.4 kg
(0.90 lbs)
0.4 kg
(1.00 lbs)
0.5 kg
(1.10 lbs)
0.5 kg
(1.20 lbs)
0.6 kg
(1.25 lbs)
75 PPM
0 kg
(0.0 lbs)
0 kg
(0.0 lbs)
0 kg
(0.0 lbs)
0 kg
(0.0 lbs)
0 kg
(0.0 lbs)
0 kg
(0.0 lbs)
0 kg
(0.0 lbs)
0 kg
(0.0 lbs)
0 kg
(0.0 lbs)
0 kg
(0.0 lbs)
0 kg
(0.0 lbs)
NOTE:
Add 0.57 kg (1.25 lb) Chlorine Stabilizer to the pool every time 22.7 kg (50 lb) of Salt is added to the pool.
The Stabilizer reading should be maintained at 75 PPM.

Pentair IntelliChlor IC20 Specifications

General

Model	IntelliChlor IC20
Type	Salt Chlorine Generator
Pool Size	Up to 20, 000 gallons
Voltage	120/240 VAC
Power Supply	External Power Center
Flow Rate	Minimum 20 GPM
Water Temperature	50°F to 104°F (10°C to 40°C)
Cell Life	10, 000 hours
Warranty	3 years
Chlorine Output	0.7 lbs/day
