3
IntelliTouch ScreenLogic User’s Guide
IntelliTouch Interfaces
Pool and Spa owners can choose one or more of the following interface options to control the IntelliTouch system
throughout their home.
• iTC15 Kit (P/N 520500) – Includes Protocol Interface Adapter and wireless router that
connects to existing Desktop or Laptop PC. This allows control of IntelliTouch pool and
spa systems via PC (requires PC with an Ethernet connection, and Windows XP
operating system).
• iTC25 Kit (P/N 520501) – Includes Wireless Personal Digital Assistant (PDA) with
3.5" color touch screen custom configured for IntelliTouch systems, wireless router, and
a Protocol Interface Adapter.
• iTC35 Kit (P/N 520502) – Includes in-wall color touch screen with Ethernet
(RJ45) connection and Protocol Interface Adapter and wireless router. The
in-wall Touch screen is custom configured for IntelliTouch systems.
• iTC45 Kit (P/N 520503) – Includes wireless Tablet with color touch screen,
Protocol Interface Adapter, and wireless router. The Tablet is custom
configured for IntelliTouch systems.
• Indoor Control Panel (P/N 520138) – 3.75’’ monochrome backlit LCD
control panel. Connects to Personality board in Load Center.
• MobileTouch (P/N 520340) – 3.75’’ monochrome backlit LCD wireless
control panel with transceiver antenna . Allows any IntelliTouch wired system
to also have a wireless remote with all the capabilities of the Indoor Control
Panel. With an average range of 300 feet, pool owners have system control
anywhere around the home or yard. Powered by a rechargeable lithium-ion
battery. Includes an AC adapter for recharging.
In-Wall Touch Screen
Digital Tablet
PDA
Indoor Control Panel
MobileTouch
