8
IntelliTouch ScreenLogic User’s Guide
Infrared Sensor: The infrared sensor lets you transfer files from your device to another infrared-compatible
device without using cable connections. Not used by IntelliTouch ScreenLogic.
Microphone: Use to record audio. Not used by IntelliTouch ScreenLogic.
CompactFlash and Secure Digital Memory Card Slots: Not used by IntelliTouch ScreenLogic.
Wireless Light: Illuminates when transmitting and receiving data.
Stylus: Use the stylus to write or draw on the screen. To remove the stylus, pull it straight up and out of the
holder. To avoid losing the stylus, store the stylus in the holder when you are not using it. Ensure that the stylus
is oriented correctly when you replace it in the slot.
Personal Digital Assistant (PDA) Description
The iTC25 (P/N 520501) Interface Kit includes a wireless touch screen PDA which is custom configured with the
IntelliTouch ScreenLogic Pool and Spa control application. This device also offers a wide range of capabilities. For
more detailed information about the PDA, refer to the manufacturers documentation shipped with the device.
PDA Front and Side Views
The following describes the PDA controls and functions:
CompactFlash card and
Secure Digital memory card
slots (top)
power button
touch screen
Navigator button
Home button
Contacts button
Calendar button
lanyard hook
microphone
Inbox button
audio connector (top)
wireless light
infrared sensor (top)
lock button
on/off button for
WLAN/Bluetooth
wireless
technology
record button
mylar
protector tab
