Pentax Optio S1 User Manual

2
Warning
• Do not disassemble or modify the camera. High voltage areas are present
inside the camera, with the risk of electric shock.
• If the camera interior is exposed due to dropping or otherwise damaging
the camera, never touch the exposed portion. There is a risk of electric
shock.
• Wrapping the strap around your neck is dangerous. Take care that small
children do not hang the strap around their necks.
• If any irregularities occur during use, such as smoke or a strange odor, stop
use immediately, remove the battery, and contact your nearest PENTAX
Service Center. Continuing to use the camera can cause a fire or electric
shock.
Caution
• Do not place your finger over the flash when discharging the flash. You
may burn yourself.
• Do not cover the flash with clothes when discharging the flash.
Discoloration may occur.
• Some portions of the camera heat up during use. There is a risk of low
temperature burns when holding such portions for long periods.
• Should the monitor be damaged, be careful of glass fragments. Also, be
careful not to allow the liquid crystal to get on your skin, in your eyes or
mouth.
• Depending on your individual factors or physical condition, the use of the
camera may cause itching, rashes or blisters. In case of any abnormality,
stop using the camera and get medical attention immediately.
Warning
• Always use the power adapter exclusively developed for this camera, with
the specified power and voltage. Using a power adapter not exclusive to
this camera, or using the exclusive power adapter with an unspecified
power or voltage can cause a fire, electric shock, or camera breakdown.
The specified voltage is 100 - 240V AC.
About the Camera
About the Power Adapter

Pentax Optio S1 Specifications

General

Megapixel	14 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	14.48 MP
Image sensor size	1/2.3 \
Supported aspect ratios	16:9
Maximum image resolution	4288 x 3216 pixels
Still image resolution(s)	640 x 480, 1920 x 1080, 3072 x 2304, 3216 x 3216, 4224 x 2376
Digital zoom	6.7 x
Optical zoom	5 x
Combined zoom	33.5 x
Focal length range	5 - 25 mm
Number of aspheric elements	4
Lens structure (elements/groups)	9/8
Video out	AV
Aperture range (F-F)	3.9 - 5.7
Camera shutter speed	1/6000 - 1/4 s
Compatible operating systems	Windows XP (SP3)/Vista/7 Mac OS X v10.3.9+
Focal length (35mm film equivalent)	28 - 140 mm
Focus	TTL
Normal focusing range	0.4 - ∞/1 - ∞ m
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Super Macro focusing range	0.05 - 0.30 m
Macro focusing range (wide)	0.1 - 0.5 m
Normal focusing range (tele)	1 - ∞ m
Normal focusing range (wide)	0.4 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	64, 80, 100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 3200, 6400, Auto
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic
Flash modes	Auto, Flash off, Red-eye reduction
Flash range (tele)	1 - 2.5 m
Flash range (wide)	0.3 - 3.6 m
Histogram	No
Scene modes	Beach, Candlelight, Children, Documents, Fireworks, Night, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia, Skin tones
White balance	Auto, Daylight, Fluorescent, Manual, Shade, Tungsten
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, POL, POR, RUS, SWE, THA, TUR
Video resolutions	320 x 240, 640 x 480 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Internal memory	42.7 MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
PictBridge	-
USB version	2.0
Product color	Black
Battery type	D‐LI78
Battery life (CIPA standard)	180 shots
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	20 mm
Width	90 mm
Height	54 mm
Weight	110 g
Weight (including battery)	126 g
