Pentax W-1502N Series User Manual

64
elevation difference(VD) will change too.But if collimate A0 with the second
method,vertical angle is locked in the direction where prism is located and
can’t range from up-and-down movement of telescope.
Operation steps Keys Display
1
Click “Offset” key.
【
Offset
】
2
Click “ANG.Offset”
key in ejecting dialog
box.
3
Select “Free VA”(or
“Lock VA”) with
stylus to to start
angle offset
measurement.(User
makes a choice on
the basis of own
demand)
