61
6000 Series Purge/Pressurization System
I/O Manual
- INPUT 3 -
INPUT 3 FUNCTION
(DISABLED)
- DISABLED -
- INPUT 3 FUNCTION -
IMMEDIATE
SHTDN
-
DOOR OPEN
ALARM
- OVERLOAD
-
CTRL PWR
RELAY
-
CTRL
OUTPUT 1
-
CTRL
OUTPUT 2
- CTRL VALVE
-
SRM
(NO)
- YES, NO -
-
INVERT INPUT
(NO)
- YES, NO -
- INPUT 4 -
INPUT4 FUNCTION
(DISABLED)
- DISABLED -
- INPUT 4 FUNCTION -
IMMEDIATE
SHTDN
-
DOOR OPEN
ALARM
- OVERLOAD
-
CTRL PWR
RELAY
-
CTRL
OUTPUT 1
-
CTRL
OUTPUT 2
- CTRL VALVE
-
SRM
(NO)
- YES, NO -
-
INVERT INPUT
(NO)
- YES, NO -
