6000 Series Purge/Pressurization System
I/O Manual
- PRESS AS INPUT -
PRESS FUNCTION
(DISABLED)
- DISABLED -
- PRESS FUNCTION - DISABLED
-
CTRL
OUTPUT 1
-
CTRL
OUTPUT 2
- CTRL VALVE
ON PRESSURE -
ON
PRESSURE
-
XX.X IN WC
(XX.X MBAR)
-
- OFF PRESSURE -
OFF
PRESSURE
-
XX.X IN WC
(XX.X MBAR)
-
- TEMP INPUT - SENSOR SETUP -
EXT SENSOR
COUNT
- XX -
- USE HUB SENSOR - HUB YES/NO -
- TEMP INPUT 1 -
TEMP FUNCTION
(DISABLED)
- DISABLED -
- TEMP FUNCTION -
IMMEDIATE
SHTDN
-
DOOR OPEN
ALARM
- OVERLOAD
-
CTRL PWR
RELAY
-
CTRL
OUTPUT 1
-
CTRL
OUTPUT 2
- CTRL VALVE
- ALARM
- SETPOINT TYPE -
*AVERAGE
SINGLE PT
-
- ON SETPOINT - XX °F (°C) -
- OFF SETPOINT - XX °F (°C) -
